Product Detail

P4 3/4/6/8inch LED Lights Ceiling 7W-30W


|
Model Code : HD03/04/06/08-P4
 Reservation Now
Spec


Description

The P4 3/4/6/8inch LED Ceiling Lights (7W-30W) are the perfect combination of style, energy efficiency, and functionality. Designed to meet the diverse lighting needs of residential and commercial spaces, these LED lights provide bright, uniform illumination while maintaining low energy consumption.

Available in multiple size options—3-inch, 4-inch, 6-inch, and 8-inch—and wattages ranging from 7W to 30W, the P4 ceiling lights are ideal for various applications, from accent lighting to general illumination. These modern ceiling fixtures deliver high performance and durability, ensuring a long lifespan and reliable lighting.

With their sleek design and advanced LED technology, the P4 LED Ceiling Lights are perfect for enhancing any European interior, from contemporary homes to stylish commercial environments.


Technical Specifications:

FeatureDetails
Light SourceSamsung LED / Sanan SMD
Lumen Efficiency100-115 lm/W
Wattage Options7W / 10W / 15W / 20W / 25W / 30W
Beam Angle90°
CCT2700K – 6000K
CRI80 / 90
MaterialDie-cast Aluminium
Cut-out SizesØ90, Ø125, Ø160, Ø200 mm
Dimensions

D106×H34, D140×H36, D180×H38, D230×H38,

D140×H40, D182×H48, D230×H53

IP RatingIP20
UGR RatingUGR < 22
Dimming OptionsTRIAC, 0-10V dimmable
CertificationCE, RoHS, LED Quality OK, IK08
Lifespan>50,000 hours
Warranty3-5 years



Why Choose the P4 3/4/6/8inch LED Ceiling Lights?

  • Energy Savings: Advanced LED technology offers excellent lighting performance with reduced energy consumption.

  • Customizable Options: Multiple sizes and wattages cater to a variety of lighting requirements.

  • Modern Appeal: A sleek design seamlessly integrates into any interior, enhancing aesthetic appeal.

  • Durability: Constructed with premium materials for long-lasting and reliable use.

  • Wide Range of Applications: Suitable for both residential and commercial lighting needs.




Data

Power(X):7W/10W;10W/15W;15W/20W/25W;20W/25W/30W
LED Chip:Samsung LED/ Sanan SMD
Beam Angle:90°
Size:

106mm*34mm;

140mm*36mm;

180mm*38mm;

230mm*38mm;

Cutout:

90-95mm;

125-130mm;

160-165mm;

200-205mm;

Driver certification:ENEC CE CB SAA
PF>0.9Flicker FREE
THD<10
Lifetime:50000hrs


Selling Points

1.Super thin downlight, less than 40mmH


2.Better surface finish than regular downlight in the market;


3.Samsung chip,better lumen output,100-105lm/W;


4.Good driver wire connection style;


5.Deep Ring also available.
